The Ultimate Checklist: Planning Your Dana 44 High Steer Conversion Committing to a heavy-duty steering upgrade is one of the most significant modifications you can make to a lifted off-road vehicle. If you are tired of battling bump steer, highway wander, and bent tie rods on your GM, Chevy, or Jeep, stepping up to a 1-ton crossover setup is the definitive cure. However, a high-steer conversion is a major structural overhaul that requires careful planning. Before you put your rig on jack stands and start tearing down your front axle, use this ultimate pre-build checklist to ensure your Dana 44 High Steer Kit installation goes flawlessly. 1. Verify Your Lift Height and Geometry Needs Crossover steering is not a modification for stock-height vehicles. The Clearance Check: An Off Road Crossover Steering System relocates your drag link high above the passenger side leaf springs. You typically need a minimum of 3 to 4 inches of suspension lift to provide enough vertical clearance between the axle and the engine crossmember for the new linkages to operate without interference. The Bump Steer Diagnosis: Assess your current geometry. Is your factory drag link pointing down at a steep angle? If so, this is the root cause of your bump steer. A crossover setup will reposition this linkage horizontally, isolating your steering input from your suspension travel. 2. Secure Unbreakable Core Components When upgrading to a 1-ton system, do not compromise on the foundational hardware. The leverage generated by 37-inch mud tires will instantly exploit any weak links in your outer knuckle assembly. Precision Knuckles: Do not attempt to drill and tap your stock knuckles. You need dedicated Dana 44 Flat Top Knuckles designed with a reinforced top mounting surface. The East West Off Road (EWO) kit includes brand-new, fully machined knuckles featuring a meticulous bottom down taper knuckle Dana 44 configuration. Billet Over Cast: Avoid cheap cast-iron steering arms at all costs. Ensure your kit includes massive 1.25-inch thick billet 1 Ton High Steer Arms Dana 44. Because billet steel is incredibly dense, it will not snap under extreme shock loads and carries a lifetime warranty. 3. Plan Your Custom Linkages (The DOM Factor) Every custom build has a unique track width, which makes pre-cut steering tubing a massive liability. The DIY Advantage: Professional fabricators prefer utilizing an EWO complete high steer kit without DOM tubing. This allows you to bolt on your knuckles and steering box, then measure the exact distance required for your specific setup. Sourcing Your Steel: Plan to source high-quality Drawn Over Mandrel (DOM) steel locally (typically 1.5-inch OD x .250-inch wall thickness). You will cut this steel to your exact measurements and weld in the massive heavy-duty joints provided in the EWO kit, resulting in a 100% custom-fit drag link and tie rod. 4. Prep for the Steering Box Swap You cannot reuse your factory 4WD steering box when executing a true crossover conversion. The 2WD Box Requirement: A Square Body Crossover Steering Conversion requires a 2WD steering box. This is because the sector shaft on a 2WD box sweeps side-to-side, providing the exact horizontal motion required for the new crossover drag link. Factory 4WD boxes sweep front-to-back, which is incompatible with crossover geometry. The Pitman Arm: Ensure you have the correct drop pitman arm to mate with the new box. The EWO GM 1 Ton Steering Upgrade makes this easy by including a fully indexed 3-inch drop pitman arm (32 splines) that bolts perfectly onto the required 2WD box. 5. Account for Fresh Consumables Since you are completely tearing down your outer knuckle assembly, it is the perfect time to replace your wearable components. Ball Joints: Never reuse old, fatigued ball joints on a newly upgraded 1-ton front end. The EWO DIY kit conveniently includes a fresh set of upper and lower Dana 44 ball joints, allowing you to completely refresh your axle's pivot points during the high-steer installation. Frequently Asked Questions (FAQs) How long does a Dana 44 high steer conversion take to complete? For an experienced fabricator with the DOM tubing already sourced and cut, the installation can be completed over a weekend. It involves removing the old knuckles, installing the new ball joints and flat top knuckles, mounting the steering box, and welding the tube adapters. Do I need specialized welding skills for the "without DOM" kit? Yes. Because you are welding the 7/8-18 tube adapters into your custom-cut DOM tubing to create the tie rod and drag link, highly proficient structural welding is required. If a steering weld fails on the highway, the results can be catastrophic. Will this kit work with a spring-under-axle (SUA) or just spring-over-axle (SOA) lifts? Crossover steering and high-steer arms are primarily designed for lifted, spring-over-axle configurations to keep the steering linkages safely above the leaf springs and out of the way of trail obstacles.
