The Missing Link in Your Lift Kit: Dana 44 High Steer Kit Upgrade You just finished installing a massive suspension lift, upgraded your shocks, and bolted on a set of heavy 37-inch mud tires. Your rig looks absolutely unstoppable sitting in the driveway. But the moment you take it out for a test drive, the reality sets in: it wanders all over the highway, and the steering wheel violently jerks left and right over every bump. The problem isn't your suspension—it’s your factory steering geometry. Upgrading to a heavy-duty Dana 44 High Steer Kit is the critical "missing link" that connects your new lift kit to reliable, precise handling. Let's break down why your lifted rig handles poorly and how a 1-ton crossover setup is the ultimate cure. Why Your New Lift Kit Ruined Your Handling Factory push-pull steering systems are engineered with very tight tolerances designed strictly for stock ride heights. When you push the chassis six to eight inches away from the front axle, you stretch those factory linkages beyond their intended limits. The Bump Steer Phenomenon Because the distance between the steering box and the axle has increased, your factory drag link is forced to point downward at a steep angle. As your new suspension travels up and down, that angled drag link physically pushes and pulls against the steering knuckle. This forces the tires to turn without your input, creating the terrifying condition known as "bump steer." Why a GM 1 Ton Steering Upgrade is the Only Fix Simply installing a drop steering arm is often just a band-aid. To truly fix the geometry and handle the added weight of oversized tires, you need to upgrade the entire system. Stepping up to 1-ton components ensures that when you bind a tire in the rocks, your tie rods and steering arms will not bend or shear under the pressure of your power steering box. Restoring Geometry with an Off Road Crossover Steering System To permanently cure steering wander and bump steer, you must completely rethink the geometry. An Off Road Crossover Steering System does this by relocating the drag link. Instead of connecting to the driver's side knuckle at a steep angle, the drag link is mounted high above the leaf springs and crosses entirely over the axle to the passenger side knuckle. This ensures the linkage remains horizontal. For classic trucks, performing a Square Body Crossover Steering Conversion removes the sloppy factory steering block, restoring a direct, responsive feel to the steering wheel. Inside the EWO Complete High Steer Kit Without DOM East West Off Road builds steering components meant to outlast the vehicle they are bolted to. Manufactured in the USA, this package acts as the ultimate Dana 44 DIY Steering Kit, providing everything a fabricator needs minus the raw steel tubing. Unbreakable 1 Ton High Steer Arms Dana 44 The secret to this kit's survival rate is the immense density of its arms. EWO includes 1.25 inch thick billet steering arms carved from domestic billet blocks. Unlike standard cast arms that can easily snap under extreme leverage, these billet arms utilize a 4-hole mounting style and carry a lifetime warranty. Precision Dana 44 Flat Top Knuckles To ensure those billet arms have a perfect foundation, this EWO complete high steer kit without DOM includes brand-new driver and passenger side flat top knuckles. They feature a precision bottom down taper knuckle Dana 44 design to guarantee your steering arms seat flawlessly and never vibrate loose on the trail. Included Heavy-Duty Hardware The massive billet arms are tapered specifically for heavy-duty Chevy 3/4 ton tie rod arms. To complete the build, the kit provides: ES2026R ES2027L drag link ends and ES2234L ES2234R tie rod ends (with grease fittings and castle nuts) Left and right 7/8-18 weld bungs (tube adapters) and jam nuts High-strength Dana 9/16”-18 studs, conical washers, and lock nuts Brand new Dana 44 upper lower ball joints The 2WD Box Crossover Steering Kit Prerequisite To successfully execute this geometry correction, you must verify your steering box. A true crossover setup requires a 2WD steering box because its sector shaft sweeps side-to-side (4WD boxes sweep front-to-back). To ensure this swap is a painless, bolt-on process, EWO includes a fully indexed 3 inch drop pitman arm 32 splines that perfectly mates with your new 2WD box.
