Cure Steering Slop: The Ultimate 1-Ton High Steer Upgrade for Chevy & Jeep There is a dirty little secret in the off-road world that no one talks about until it is too late: lifting your solid-axle truck ruins your factory steering. If you have ever hit a bump on the highway and felt your steering wheel violently jerk out of your hands, or if you constantly have to "herd" your truck to keep it in a straight line, your factory steering linkage is failing you. If you want to restore factory-like handling while running massive mud-terrain tires, you need a heavy-duty 1 Ton Steering Upgrade Chevy K5 and Jeep enthusiasts can trust. Let's explore how completely overhauling your front end will cure your steering slop for good. The Hidden Cause of Sloppy Steering on Lifted Rigs When you install a suspension lift, you increase the vertical distance between the frame-mounted steering box and the axle-mounted knuckle. The factory push-pull steering drag link must now stretch down at a severe angle to connect the two. How to Fix Bump Steer Lifted Chevy Trucks Experience Because the drag link is sitting at a steep angle, it operates on a restricted arc. When your suspension travels up or down, that angled linkage pushes or pulls against your steering box, forcing the vehicle to steer itself. This terrifying phenomenon is called bump steer. The absolute best way to Fix Bump Steer Lifted Chevy trucks and custom SUVs suffer from is to flatten out the drag link. By installing a high steer crossover setup, you relocate the linkage from the driver's side factory position, raising it high above the leaf springs and crossing it completely over to the passenger side. Whether you need a heavy-duty Squarebody Crossover Steering Kit or you are tackling a Jeep Dana 44 high steer conversion, this geometry correction provides effortless, precise handling. The Definitive Chevy 10 Bolt High Steer Conversion To safely correct your geometry, you need specialized hardware that can handle the extreme leverage of oversized tires. The East West Offroad 1 ton steering system is the industry standard because it replaces fatigued factory cast iron with massive, unyielding American-made components. The Power of a US Made Dana 44 Knuckle A safe high steer system requires a perfectly flat, reinforced mounting surface. This kit includes a brand-new US Made Dana 44 Knuckle. You absolutely need this Dana 44 passenger side flat top knuckle to safely bolt down your new linkage. Manufactured by EWO, this piece is uniquely machined with a Chevy 10 bolt bottom up taper knuckle design. This precise engineering allows your heavy-duty tie rod ends to mount from the bottom facing upward, maximizing your geometric clearance away from your leaf springs to prevent binding during heavy articulation. Massive 1.25 Inch Thick Billet Steering Arms Bolted securely to that Dana 44 Flat Top Knuckle are the legendary Dana 44 High Steer Arms. Bypassing cheap imported castings, EWO supplies massive 1.25 inch thick billet steering arms featuring a robust 4-hole design. Machined domestically by American workers and carrying a lifetime warranty, they are locked into place using ultra-strong Chromoly 9/16 studs Dana 44, heavy-duty conical washers, and lock nuts. The Smart Fabricator's DIY Dana 44 Steering Kit Custom axle builds and unique suspension setups require tailored linkage lengths. This kit is thoughtfully engineered for fabricators who want top-tier strength without blowing their entire build budget on freight. Why Choose a Crossover Steering Kit Without DOM Tubing Shipping heavy steel structural tubing across the country is astronomically expensive. By intentionally offering this as a crossover steering kit without DOM tubing, EWO saves you a massive amount of money. You receive all the complex, precision-machined hardware to assemble your Chevy 10 bolt Jeep crossover steering setup, including the left and right 7/8 – 18 weld bungs and jam nuts. You simply purchase the heavy raw DOM steel tubing at your local metal supply yard, cut it to your custom length, and weld in the bungs to complete your Dana 44 Crossover Steering Kit.
