A number of advanced phasing strategies are shown in this article, including how to leverage the new double pattern feature of Revit 2019 and the new phasing in view filter added in Revit 2022. 1. Strategy of Using Double Pattern with Phases Revit's interface has undergone a few changes since then. Phases have drastically changed in Revit 2019's update. Double patterns are introduced in it. To make an existing brick wall, you can combine the pattern of the phase with the material pattern in the example below. With a phase graphics override, you can easily represent existing elements without losing the pattern of the materials. In previous versions of Revit, this was not possible.
